2PC 3000 PSI Ball Valve NPT A105

Port size：1/2"~2" (DN15~DN50)
Pressure：3000 PSI WOG or others
Structure：3PC,Full bore
Medium：Water,steam,oil,gas,etc.
Temperature :-29～180℃
Body material：A105 LF2 F304 F316 F316L or others
Connection：Threaded end or BW, SW is optional
Feature：Different material is optional

Product Description

3000 PSI Ball Valve Manufacturer, Factory and Supplier with best price for sale. 2PC 3000 PSI Ball Valve NPT A105 is NPT threaded end, socket welded end optional, forged steel A105 material, F304 F316 or other forged material optional, full bore, floating ball structure, 2PC 3000 PSI Ball Valve NPT A105 is mainly used for long-distance pipeline transportation of oil and natural gas and urban gas piping systems. 2PC 3000 PSI Ball Valve NPT A105 has the ability to withstand pipeline stress, as well as safety, weather resistance, long-term use of reliability seal design structure, which is fully considered in the design.The driving mode of 2PC 3000 PSI Ball Valve NPT A105 can be manual, worm wheel, pneumatic and electric, the connection mode can be flange and welding, the structure is three-stage, the sealing structure can be soft seal and hard seal.

2PC 3000 PSI Ball Valve NPT A105 Feature:
1. All parts are forgings
2. Lower mounted valve stem and inverted sealing structure of equipment are adopted
3. The use of Mosaic valve seat, seat back equipment O ring, to ensure that the medium leakage
4. The sealing surface use nylon,PTFE,Delvon,PEEK or metal seat for good perfornamce and long service life.
5. Floating ball, full bore or reduce bore.
6. ISO5211 mounting pad for option.
7. Blow-out proof stem design.
8. Anti-static design and API 607 Fire Safe Design available
9. Operation: Hand wheel, Worm wheel, Pneumatic actuator & Electric Actuator.

2PC 3000 PSI Ball Valve NPT A105 Specification:

Product Name	2PC 3000 PSI Ball Valve NPT A105
1. Material	A105 or F304,F316 etc.
2. Size	1/4~2 inch ( DN10~DN50)
3. Port	Full Port
4. Working Pressure	3000 PSI or others
5. Connection Ends	Threaded or Socket welded or others
6. Working Temp.	-20~180ºC,-46~450ºC, or according to customer requirements for different industry.
7. Suitable Medium	Water, Natural Gas, Oil and some corrosive liquid
8. Operation	Handle operated, Locking device is option
9. Inspection & Testing	According to API598
