China super duplex ball valve manufacturer

China super duplex ball valve manufacturer,super duplex stainless steel ball valve factory and supplier in China,Super duplex ball valve is floating ball with full bore or reduced bore,2 PC or 3 PC structure,Super duplex ball valve have excellent resistance to point, crack and uniform corrosion, and are highly resistant to stress corrosion cracking.Super duplex ball valve is used in water treatment, seawater desalination, chemical and other places where corrosion resistance is required.

Super duplex ball valve specification
Pressure Class: PN1.6-10.0 MPA CLASS150-600lb
Nominal size: DN15-DN600 1/2"-24"
Driving mode: handle, worm gear, pneumatic, hydraulic, electric
Applicable medium: oxidizing corrosive medium.
Design standard: GB/T12237, API6D, ASME B16.34
Structure length: GB/T12221, API6D, ASME B16.10
Flanges: HG, GB, JB, API, ANSI, ISO, BS, DIN, NF, JIS
Test standard: JB/T9092, GB/T13927, API6D, API598

Super duplex ball valve material feature
Compared with austenitic stainless steel,Super duplex ball valve strength is higher and its resistance to intercrystalline corrosion and chloride stress corrosion is improved obviously.Super duplex ball valve has excellent corrosion resistance and is also a kind of nickel stainless steel.
In corrosion resistance, especially the medium environment is more harsh (such as seawater, chloride ion content is higher) under the conditions,Super duplex ball valve resistance pitting corrosion, crevice corrosion, stress corrosion and corrosion fatigue performance is obviously better than ordinary austenitic stainless steel, can be comparable with high alloy austenitic stainless steel.
